607nm激光器
LL607-400mw

LD PUMPED ALL-SOLID-STATE RED LASER AT 607nm DPSS red laser at 607nm is made features of ultra compact, long lifetime and easy operating, which is widely used in measurement, spectrum analysis as the substitute for He-Ne lasers.

Part number	LL607-400mw
Wavelength (nm)	607±3
Operating mode	CW
Output power (mW)	1-400
Power stability (rms, over 4 hours)	<3%, <2%, < 1%, 0.5%
Transverse mode	TEM00
M2 factor	< 1.2
Beam diameter at the aperture ( 1/e2, mm)	<2.0
Beam divergence, full angle (mrad)	< 1.5
Polarization Ratio	> 100:1, (Horizontal or Vertical Optional)
Warm-up time (minutes)	<5
Pointing stability after warm-up (mrad)	<0.05
Beam height from base plate (mm)	27.4
Operating Temperature (°C)	10-35
Modulation option	TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz,
Power supply (90-264VAC)	PSU
Expected lifetime (hours)	10000
Warranty	1 year
