579nm激光器
LL579-250mw


LD PUMPED ALL-SOLID-STATE Q-SWITCHED YELLOW LASER at 577nm CNI’s All solid state Q-switched yellow laser at 579nm has the features of ultra compact, easy operating, it is widely used in micro-electronics, metrology and material processing ,laser medical treatment, scientific

Central wavelength (nm)	579±2
Operating mode	Acousto-Optic Q-switched
Average power (mW)	1-250
Rep. rate (kHz)	10
Pulse duration (ns)	< 15
Single pulse energy (µJ)	1~25
Peak power(kW)	1.7
Beam diameter at the aperture ( 1/e2, mm)	<3
Beam divergence, full angle (mrad)	<2
Power stability (rms, over 4 hours)	<3%,5%
Beam height from base plate (mm)	120
Warm-up time (minutes)	< 10
Cooled method	Air Cooled
Power supply	PSU-AOM (3U)
Expected lifetime (hours)	10000
Warranty period	1 year
