582nm激光器

582nm激光器

产品说明：582nm激光器 LL582-100mw LD PUMPED ALL-SOLID-STATE YELLOW LASER All solid state at 582nm blue laser features of ultra compact long lifetime low cost and easy operating which is used in laser display medical treatment scientific resea

订购热线：0431-81759561

产品详细

582nm激光器
LL582-100mw

LD PUMPED ALL-SOLID-STATE YELLOW LASER All solid state at 582nm blue laser features of ultra compact, long lifetime, low cost and easy operating, which is used in laser display, medical treatment, scientific research, etc.

Wavelength (nm)	582±2
Operating mode	CW
Output power (mW)	> 10, 20, ..., 100
Power stability (rms, over 4 hours)	<3%, <5%
Transverse mode	Near TEM00
Beam divergence, full angle (mrad)	<3
Beam diameter at the aperture ( 1/e2,mm)	~4
Polarization ratio	> 100:1
Beam height from base plate (mm)	100
Warm-up time (minutes)	< 10
Operating temperature (C)	15~30
Power supply (90-264VAC)	PSU-W-FDA
Expected lifetime (hours)	10000
Warranty period	1 year
