601nm激光器
LLQ-250mw

LD PUMPED ALL-SOLID-STATE Q-SWITCHED LASER at 601nm All solid state Q-switched laser at 601nm has the features of ultra compact, easy operating, which is widely used in micro-electronics, metrology and material processing ,laser medical treatment, scientific experiment, etc

Central wavelength (nm)	601±2
Operating mode	Acousto-Optic Q-switched
Average power (mW)	1~250
Rep. rate (kHz)	10
Pulse duration (ns)	< 10
Single pulse energy (µJ)	1~25
Peak power(kW)	2.5
Beam diameter at the aperture ( 1/e2,mm)	<3
Beam divergence, full angle (mrad)	<2
Power stability (rms, over 4 hours)	<3%, <5%
Beam height from base plate (mm)	120
Warm-up time (minutes)	< 10
Power supply	PSU-AOM (3U)
Expected lifetime (hours)	10000
Warranty period	1 year
