552nm激光器

产品说明：552nm激光器 LL552-300mw LD PUMPED ALL-SOLID-STATE GREEN LASER DPSS green laser at 552nm is made features of ultra compact long lifetime and easy operating which is used in measurement medical treatment scientific research etc.

订购热线：0431-81759561

产品详细

552nm激光器
LL552-300mw

LD PUMPED ALL-SOLID-STATE GREEN LASER DPSS green laser at 552nm is made features of ultra compact, long lifetime and easy operating, which is used in measurement, medical treatment, scientific research, etc.

Part number	LL552-300mw
Wavelength (nm)	552± 1
Operating mode	CW
Output power (mW)	1-300
Power stability (rms, over 4 hours)	< 10%, <5%, <3%
Transverse mode	Near TEM00
M2 factor	<2.0
Beam diameter at the aperture ( 1/e2, mm)	<2.0
Beam divergence, full angle (mrad)	<2.0
Polarization Ratio	> 100:1, (Horizontal or Vertical Optional)
Warm-up time (minutes)	<5
Pointing stability after warm-up (mrad)	<0.05
Beam height from base plate (mm)	27.4
Operating Temperature (°C)	10-35
Modulation option	TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz
Power supply (90-264VAC)	PSU-H-LED
Expected lifetime (hours)	10000
Warranty	1 year
