558nm激光器
LL558-500mw

LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 558nm All solid state 558 nm yellow green laser is made features of ultra compact, long lifetime and easy operating, which is widely used in laser medical treatment, scientific experiment, optical instrument, etc.

Part number	LL558-500mw
Wavelength (nm)	558± 1
Operating mode	CW
Output power (mW)	1-500
Power stability (rms, over 4 hours)	<3%, <2%, < 1%
Transverse mode	TEM00
M2 factor	< 1.2
Beam diameter at the aperture ( 1/e2, mm)	<2.0
Beam divergence, full angle (mrad)	1.5
Polarization Ratio	> 100:1, (Horizontal or Vertical Optional)
Warm-up time (minutes)	<5
Pointing stability after warm-up (mrad)	<0.05
Beam height from base plate (mm)	27.4
Operating Temperature (°C)	10-35
Modulation option	TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz,
Power supply (90-264VAC)	PSU-H-LED/
Expected lifetime (hours)	10000
Warranty	1 year
