335nm激光器

产品说明：335nm激光器 LD PUMPED ALL-SOLID-STATE CW UV LASER All solid state 335nm UV laser is made features of ultra compact long lifetime cost -effectiveness and easy operating which is used in DNA sequencing flow cytometry cell sorting opti

订购热线：0431-81759561

产品详细

335nm连续激光器 LL335-60mw

LD PUMPED ALL-SOLID-STATE CW UV LASER All solid state 335nm UV laser is made features of ultra compact, long lifetime, cost -effectiveness and easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, measurement, physics experiment, laser rapid modeling, etc.

Wavelength (nm)	335± 1
Operating mode	CW
Output power (mW)	1-60
Power stability (rms, over 4 hours)	<5%, <3%
Transverse mode	Near TEM00
M2 factor	<2.0
Beam diameter at the aperture ( 1/e2, mm)	< 1.5
Beam divergence, full angle (mrad)	<2.5
Polarization Ratio	>50:1, (Horizontal or Vertical Optional)
Warm-up time (minutes)	< 10
Pointing stability after warm-up (mrad)	<0.05
Beam height from base plate (mm)	27.4
Operating Temperature (°C)	10-35
Modulation option	TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz, 10kHz-30kHz; and Analog modulation optional
Power supply (90-264VAC)	PSU-H-LED/
Warranty	1 year
